PAC500 1500mm Length 10m/Min Accumulation Roller Conveyor

Product Categories
Pengya Intelligent Technology (Shanghai) Co., Ltd.
Contact Now

PAC500 1500mm Length 10m/Min Accumulation Roller Conveyor

Place of Origin : shanghai

Brand Name : pengya

Certification : ISO

MOQ : one unit

Price : Please Contact Us For The Price

Packaging Details : wood

Delivery Time : 5-8work days

Payment Terms : TT,TLC,

Supply Ability : For more than a week

Model Number : PAC500

Can be carrying amount : 500k g/m

Roller size (od * thickness) : Φ60.5*t2.3

The shaft : 12 mm long

bearing : Low noise type

Sprocket teeth (chain * number of teeth) : No. 50 * 8 individual

Fuselage width (outside frame · outside fuselage) : W+125mm

Roller width W : 600`1200mm

Actual width dimensions of roller : W mm

Roller pitch P : 75.100.150mm

Fuselage length L(multiple tooth spacing) : 1500`12000mm

Fuselage high H(FL 'roller feeding surface) : 570`12000mm(Adjustment + - 50mm)

The motor capacity : 0.4.0.75.1.5kW

Contact Now

Pallet Flow Series PAC500 570-1200mm –three-phase 200W Pallet Flow Series

PAC tray friction accumulator conveyor

The tray special accumulative conveyor equipped with the pipeline pressure equipment is driven by the chain to complete the transport. The tower is equipped inside the roller with a cumulative structure for the simple use of the conveyor.

model PAC500 (PZP500) PAC1000 (PZP1000)
Can be carrying amount 500k g/m 1000kg/m
Roller size (od * thickness) Φ60.5*t2.3 Φ76.3*t3.8
The shaft 12 mm long 17 mm long
bearing Low noise type Low noise type
Sprocket teeth (chain * number of teeth) No. 50 * 8 individual No. 60 * 9 individual
Fuselage width (outside frame · outside fuselage) W+125mm W+150mm
Roller width W 600`1200mm 800·1500mm
Actual width dimensions of roller W mm W-3mm
Roller pitch P 75.100.150mm 100.150.200mm
Fuselage length L(multiple tooth spacing) 1500`12000mm 1500(P200in case 1600)`12000mm
Fuselage high H(FL 'roller feeding surface) 570`12000mm(Adjustment + - 50mm) 630`1200mm(adjust 50mm up and down)
The motor capacity 0.4.0.75.1.5kW 0.2.0.4.0.76kw(a pair of motors)

The state of accumulation

PAC is a low-pressure accumulative conveyor, so it controls the tray of the conveyor and accumulates the transmission.

PAC 500( 500kg/m) PAC1000 (1000kg/m)

PAC500 1500mm Length 10m/Min Accumulation Roller Conveyor

PAC500 1500mm Length 10m/Min Accumulation Roller Conveyor

Order sample

Model Shape roller width fuselage length fuselage length driving force fuselage height motor capacity carrying speed cycle number
PaC500 L W800 P75 L8025 M H600 0.4kw 10m/min 50HZ

PAC500 1500mm Length 10m/Min Accumulation Roller Conveyor
